We support the forefront technology with the reliable quality of our products.

Characteristic

  • Effectiveness of trimming lasts long due to the excellent anti-abrasion resistance and anti-impact resistance respectively.
  • Our　severe quality control system in accordance with the progress of the industry is appreciated and relied on by various industrial segments such as trimming of the semiconductor(lead-frame)and many kinds of the removal of the coatings.
  • We have products line-ups with various hardness and density in accordance with many kinds of molded materials.
  • Various applications are available in choice of shapes-polygon or globular-and sizes of the particles.
  • Decrease of the maintenance cost of the blasting equipments is available as the abrasion of the equipment is very few.
  • Both dry and wet types are available.

Applications

Cleaning Processing :
Aluminum parts, Molds, Die-casting products, Adhesives,Removal of the coatings.
Trimming Processing :
Electronic parts, Die-casting products,Plastic molded materials,Nonferrous metals and Flexible
　　　　　　　　　　　　productssuch as rubber.
Surface Finishing Processing :
Plastic molded materials, Flexible metal materials.
Pre-Treatment :
Plating, Adhesion, Coating, Soldering
Scale Removal :
Removal of the oxidized film of various materials.

Larger photo

Urea resin(polygon) Safety Data Sheet
Melamine resin(polygon) Safety Data Sheet
The colorings of Urea and Melamine resin Media are a bit of uneven according to the Production lots .
Unsaturated polyester resin（polygon） Safety Data Sheet
Acrylic Acid resin (polygon) Safety Data Sheet
Acrylic Acid resin (globular) Safety Data Sheet
Glass beads (globular)
PET resin compound (polygon+(globular)) Safety Data Sheet

Plastic Media　MIRACLE　MEDIA Series　Sizes

Sizes Particle Range(μm) MIL Standard range(μm)
#12 2360-1700
#18 1700-850
#20 1180-850 1190-840
#25 1180-600
#30 850-600 840-580
#40(80) 600-425 580-420
#50 600-250
#60(150) 425-250 420-250
#70 355-180
#80(180) 250-180 250-150
#100(320) 180-75
#120 150-53
#220 212-90
#400 150-53
#80 600-212
#80S 600-355
#150S 355-212
#100(0.1) 212-53
#200(0.2) 250-125
#300(0.3) 425-212

Dry Blast Test　Cutting power & amount of consumption

Media type #40 #60 #80 #100 Barcol
MIRACLE MEDIA　M(Melamine)　
(Mohs)4 (Barcol)60-70		 4.0 2.0 1.7 1.5 middle
MIRACLE MEDIA　U(Urea)　　
3.5 50-65		 2.0 1.5 1.0 0.5 much
MIRACLE MEDIA　A(Acrylic)　
3.5 50-70		 1.8 1.3 0.8 0.4 very little
MIRACLE MEDIA　PE(Unsaturated polyester)
3 37-43		 0.7 0.5 0.3 0.1 little

Packing types

3 ply kraft paper bag corrugated fiberboard box fiber drum
Width 51.5cm Width 28cm Diameter 58cm
Length 80cm Length 43cm -
Height -- Height 35.5cm Height 82cm
Net wt. 20kg Net wt. 20kg Net wt. 125kg
(250LB)
3 ply kraft paper  -   -
